HR10A-7P-4S(73)

The HR10 series connectors are push-pull coupling
type micro-connectors.They have been developed
in response to customers’ needs for miniaturization,
high density, and easy handling.The HR10 series
connectors offer light weight and assure high
reliavility and durability as well as easy “push-pull”
operation.
You may apply the HR10 series connectors to all
kinds of small-sized electronic equipment requiring
high reliability.However, these simple but refined
connectors are most suitable for portable electronic
equipment which requires good appearance.

Category: Connectors

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

1. “A LITTLE GIANT”
The most compact HR10 series is as slender as a cigarette but it fits every application with well-balanced, simplified
layout in limited space.
2. Easy “PUSH-PULL” OPERATION
One touch “push-pull” coupling mechanism assures easy and quick connecting and disconnecting. You can couple it
accurately just by pushing any part of the connector housing.
3. Polarization
Five-key system permits only one way of coupling so that you can find right position to connect even when blind mating.
4. Protection of connection pin
A connector pin is located to avoid any damage which may be caused when blind mating.
5. High density
The space-saving “push-pull” mechanism facilitates multi-installation of connectors.
6. Easy wiring and mounting
No use of screws makes wireing and mounting easier.
7. Simple and refined appearance
Simple and well designed connectors with matte finish enhance the appearance of the equipment.
