HCPL-J312-500E
INQUIRY ONLINE
|
Category
|
Isolators
Isolators – Gate Drivers
|
|
|
Mfr
|
Broadcom Limited
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Technology
|
Optical Coupling
|
|
|
Number of Channels
|
1
|
|
|
Voltage – Isolation
|
3750Vrms
|
|
|
Common Mode Transient Immunity (Min)
|
25kV/µs
|
|
|
Propagation Delay tpLH / tpHL (Max)
|
500ns, 500ns
|
|
|
Pulse Width Distortion (Max)
|
300ns
|
|
|
Rise / Fall Time (Typ)
|
100ns, 100ns
|
|
|
Current – Output High, Low
|
2A, 2A
|
|
|
Current – Peak Output
|
2.5A
|
|
|
Voltage – Forward (Vf) (Typ)
|
1.6V
|
|
|
Current – DC Forward (If) (Max)
|
25 mA
|
|
|
Voltage – Output Supply
|
15V ~ 30V
|
|
|
Grade
|
–
|
|
|
Qualification
|
–
|
|
|
Operating Temperature
|
-40°C ~ 100°C
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
8-SMD, Gull Wing
|
|
|
Supplier Device Package
|
8-DIP Gull Wing
|
|
|
Approval Agency
|
CSA, IEC/EN/DIN, UR
|
|
|
Base Product Number
|
HCPL-J312
|
