HCPL-0631-500E
INQUIRY ONLINE
|
Category
|
Isolators
Optocouplers, Optoisolators
Logic Output Optoisolators
|
|
|
Manufacturer
|
Broadcom Limited
|
|
|
Series
|
–
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Number of Channels
|
2
|
|
|
Inputs – Side 1/Side 2
|
2/0
|
|
|
Voltage – Isolation
|
3750Vrms
|
|
|
Common Mode Transient Immunity (Min)
|
10kV/µs
|
|
|
Input Type
|
DC
|
|
|
Output Type
|
Open Collector, Schottky Clamped
|
|
|
Current – Output / Channel
|
50 mA
|
|
|
Data Rate
|
10MBd
|
|
|
Propagation Delay tpLH / tpHL (Max)
|
100ns, 100ns
|
|
|
Rise / Fall Time (Typ)
|
24ns, 10ns
|
|
|
Voltage – Forward (Vf) (Typ)
|
1.5V
|
|
|
Current – DC Forward (If) (Max)
|
15mA
|
|
|
Voltage – Supply
|
4.5V ~ 5.5V
|
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
8-SOIC (0.154″, 3.90mm Width)
|
|
|
Supplier Device Package
|
8-SO Tall
|
|
|
Base Product Number
|
HCPL-0631
|
