ERJ-P06F12R0V

● ESD surge characteristics superior to standard metal film resistors
● High reliability : Metal glaze thick film resistive element and three layers of electrodes
● Suitable for both reflow and flow soldering
● High power 0.20 W : 0603 inch / 1608 mm size (ERJP03)
0.20 W : 0402 inch / 1005 mm size (ERJPA2)
0.33 W : 0603 inch / 1608 mm size (ERJPA3)
0.50 W : 0805 inch / 2012 mm size (ERJP06), 1210 inch / 3225 mm size (ERJP14)
0.66 W : 1206 inch / 3216 mm size (ERJP08)
● High precision, High voltage, High resistance value (ERJPM8)
: Limiting element voltage 500 V, Resistance tolerance ±1 %, TCR ±100 (x 10-6 / K)
● Reference standard : IEC 60115-8，JIS C 5201-8，JEITA RC-2134C
● AEC-Q200 compliant
● RoHS compliant
