EL3H7(B)(TA)-G

OPTOISOLATOR 3.75KV TRANS 4-SSOP

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    Category
    Isolators
    Optoisolators
    Transistor, Photovoltaic Output Optoisolators
    Manufacturer
    Everlight Electronics Co Ltd
    Series
    Packaging
    Tape & Reel (TR)
    Cut Tape (CT)
    Digi-Reel®
    Part Status
    Active
    Number of Channels
    1
    Voltage – Isolation
    3750Vrms
    Current Transfer Ratio (Min)
    130% @ 5mA
    Current Transfer Ratio (Max)
    260% @ 5mA
    Turn On / Turn Off Time (Typ)
    Rise / Fall Time (Typ)
    5µs, 3µs
    Input Type
    DC
    Output Type
    Transistor
    Voltage – Output (Max)
    80V
    Current – Output / Channel
    50mA
    Voltage – Forward (Vf) (Typ)
    1.2V
    Current – DC Forward (If) (Max)
    50 mA
    Vce Saturation (Max)
    200mV
    Operating Temperature
    -55°C ~ 110°C
    Mounting Type
    Surface Mount
    Package / Case
    4-SOIC (0.173″, 4.40mm Width)
    Supplier Device Package
    4-SSOP
    Base Product Number
    EL3H7
