EEE-FT1H331GP
INQUIRY ONLINE
|
Category
|
Capacitors
Aluminum Electrolytic Capacitors
|
|
|
Mfr
|
Panasonic Electronic Components
|
|
|
Series
|
FT
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Capacitance
|
330 µF
|
|
|
Tolerance
|
±20%
|
|
|
Voltage – Rated
|
50 V
|
|
|
ESR (Equivalent Series Resistance)
|
120mOhm @ 100kHz
|
|
|
Lifetime @ Temp.
|
5000 Hrs @ 105°C
|
|
|
Operating Temperature
|
-55°C ~ 105°C
|
|
|
Polarization
|
Polar
|
|
|
Ratings
|
AEC-Q200
|
|
|
Applications
|
Automotive
|
|
|
Ripple Current @ Low Frequency
|
585 mA @ 120 Hz
|
|
|
Ripple Current @ High Frequency
|
900 mA @ 100 kHz
|
|
|
Lead Spacing
|
–
|
|
|
Size / Dimension
|
0.394″ Dia (10.00mm)
|
|
|
Height – Seated (Max)
|
0.413″ (10.50mm)
|
|
|
Surface Mount Land Size
|
0.406″ L x 0.406″ W (10.30mm x 10.30mm)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
Radial, Can – SMD
|
|
|
Base Product Number
|
EEE-FT
|
