ECMF02-2HSMX6

The ECMF02-2HSMX6 is an ESD protected common mode filter especially designed for USB3.2 Tx/Rx
differential pair, for host and device. The USB3.2 is actually made of 3 differential pairs. The first differential
pair supports the high speed USB mode (also called USB2.0 mode). The 2 other differential pairs are used
to support the super speed USB mode in full duplex. Bit rate on super speed USB can reach 5 Gbps. The
ECMF02-2HSMX6 is able to filter the common mode noise from 300 MHz to 6 GHz, helping to make the
application compliant with the electromagnetic interference emission standard such as CISPR22 or FCC part 15,
or EN55022 and avoiding antenna desense on mobile phones, WiFi/Bluetooth, GPS,/GNSS frequencies. At the
same time, the ECMF02-2HSMX6 keeps the high speed signal integrity and provides an efficient ESD protection.
More application information available in following AN:
• Application Note AN4356: “Antenna desense on handheld equipment”
• Application Note AN4511: “Common Mode filters”
• Application Note AN4540: “MHL link filtering and protection”

Category: Filters

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE

SPECIFICATION

• High common mode attenuation:
– -10 dB at 300 MHz
– -20 dB at 2.4 and 5 GHz
– -15 dB from 500 MHz to 6 GHz
• Compliant with USB3.2 gen 2 eye diagram
• Small and thin package 1.5 x 1.7 x 0.5 mm
• RoHS compliant
• High reduction of parasitic elements through integration
• ESD protection compliant with IEC 61000-4-2 level 4 standards (8 kV contact)
Benefits
• Suppress the common mode noise but keep signal integrity
• Low PCB space consumption
• Save components count
• Make the application robust against ESD strikes from external environment
