C0805C104K1RAC7800

KEMET’s X7R dielectric features a 125°C maximum
operating temperature and is considered temperature
stable. The Electronics Components, Assemblies and
Materials Association (EIA) characterizes X7R dielectric as
a Class II material. Components of this classification are
fixed, ceramic dielectric capacitors suited for bypass and
decoupling applications or for frequency discriminating
circuits where Q and stability of capacitance characteristics
are not critical. X7R exhibits a predictable change in
capacitance with respect to time and voltage, boasting a
minimal change in capacitance with reference to ambient
temperature. Capacitance change is limited to ±15% from
−55°C to +125°C.

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    • −55°C to +125°C operating temperature range
    • Lead (Pb)-free, RoHS, and REACH Compliant
    • Temperature stable dielectric
    • EIA 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220,
    and 2225 case sizes
    • DC voltage ratings of 6.3 V, 10 V, 16 V, 25 V, 35 V, 50 V,
    100 V, 200 V, and 250 V
    • Capacitance offerings ranging from 10 pF to 47 μF
    • Available capacitance tolerances of ±5%, ±10%, and ±20%
    • Non-polar device, minimizing installation concerns
    • 100% pure matte tin-plated termination finish allowing for
    excellent solderability
    • SnPb termination finish option available upon request
    (5% Pb minimum)
