BAT54AWFILMY
INQUIRY ONLINE
|
Category
|
Discrete Semiconductor Products
Diodes
Rectifiers
Diode Arrays
|
|
|
Manufacturer
|
STMicroelectronics
|
|
|
Series
|
Q
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Diode Configuration
|
1 Pair Common Anode
|
|
|
Technology
|
Schottky
|
|
|
Voltage – DC Reverse (Vr) (Max)
|
40 V
|
|
|
Current – Average Rectified (Io) (per Diode)
|
300mA (DC)
|
|
|
Voltage – Forward (Vf) (Max) @ If
|
900 mV @ 100 mA
|
|
|
Speed
|
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Reverse Recovery Time (trr)
|
5 ns
|
|
|
Current – Reverse Leakage @ Vr
|
1 µA @ 30 V
|
|
|
Operating Temperature – Junction
|
-40°C ~ 150°C
|
|
|
Grade
|
Automotive
|
|
|
Qualification
|
AEC-Q101
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
SC-70, SOT-323
|
|
|
Supplier Device Package
|
SOT-323
|
|
|
Base Product Number
|
BAT54
|
