ACM70V-701-2PL-TL00

◯The storage period is within 12 months. Be sure to follow the storage conditions (temperature: 5 to 40°C, humidity: 10 to 75%
RH or less).
If the storage period elapses, the soldering of the terminal electrodes may deteriorate.
◯Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.).
◯Soldering corrections after mounting should be within the range of the conditions determined in the specifications.
If overheated, a short circuit, performance deterioration, or lifespan shortening may occur.
◯When embedding a printed circuit board where a chip is mounted to a set, be sure that residual stress is not given to the chip
due to the overall distortion of the printed circuit board and partial distortion such as at screw tightening portions.
◯Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set
thermal design.
◯Carefully lay out the coil for the circuit board design of the non-magnetic shield type.
A malfunction may occur due to magnetic interference.
◯Use a wrist band to discharge static electricity in your body through the grounding wire.
◯Do not expose the products to magnets or magnetic fields.
◯Do not use for a purpose outside of the contents regulated in the delivery specifications.
◯The products described in this catalog are intended to be installed in automobiles or automotive electronic equipment (AV
equipment, telecommunications equipment, home appliances, amusement equipment, computer equipment, personal
equipment, office equipment, measurement equipment, industrial robots) and to be used in automobiles (including the case
where the said automotive product is mounted in a vehicle) or standard applications as general electronic equipment in
automotive applications or standard applications as general electronic equipment in automotive applications in accordance with
the scope and conditions described in this specification, while the said automotive or general electronic equipment including the
said product is intended to be used in the usual operation and usage methods, respectively. Other than automotive or
automotive products are not designed or warranted to meet the requirements of the applications listed below, whose
performance and/or quality requires a more stringent level of safety or reliability, or whose failure, malfunction or defect could
cause serious damage to society, person or property.
Please understand that we are not responsible for any damage or liability caused by use of the products in any of the applications
below or for any other use exceeding the range or conditions set forth in this specification sheet.
If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or
conditions set forth in this specification, please contact us.
