82_MMBX-S50-0-1/111_NH

Electrical Data
Impedance 50 Ω
Interface frequency max. 12.4 GHz
Frequency range DC to 2.5 GHz 2.5 to 6 GHz 6 to 12.4 GHz
Return loss ≥ 26 dB ≥ 25 dB ≥ 7 dB
Mechanical Data
Board mounting type surface mount
Weight 0.0003 kg
Environmental Data
Operating temperature -55 °C to 155 °C
2011/65/EU (RoHS – including
2015/863 and 2017/2102)
compliant
