    74HC597PW,118

    The 74HC597; 74HCT597 is an 8-bit shift register with input flip-flops. It consists of an 8-bit storage
    register feeding a parallel-in, serial-out 8-bit shift register. Both the storage register and the shift
    register have positive edge-triggered clocks. The shift register also has direct load (from storage)
    and clear inputs. Inputs include clamp diodes that enable the use of current limiting resistors to
    interface inputs to voltages in excess of VCC.

    Category:

    Download Details PDF
    Notice:

    In stock will ship in 2 days. Real-time inventory pls confirm with us.

    INQUIRY ONLINE




      SPECIFICATION

      • Wide supply voltage range from 2.0 V to 6.0 V
      • CMOS low power dissipation
      • High noise immunity
      • Input levels:
      • For 74HC597: CMOS level
      • For 74HCT597: TTL level
      • 8-bit parallel storage register inputs
      • Shift register has direct overriding load and clear
      • Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
      • Complies with JEDEC standards
      • JESD8C (2.7 V to 3.6 V)
      • JESD7A (2.0 V to 6.0 V)
      • ESD protection:
      • HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
      • CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
      • Multiple package options
      • Specified from -40 °C to +85 °C and from -40 °C to +125 °C
