53261-0971

Connector Header Surface Mount, Right Angle 9 position 0.049″ (1.25mm)

Category:

Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    Mfr Molex
    Series PicoBlade 53261
    Packaging Tape & Reel (TR)
    Cut Tape (CT)
    Digi-Reel®
    Part Status Active
    Connector Type Header
    Contact Type Male Blade
    Pitch – Mating 0.049″ (1.25mm)
    Number of Positions 9
    Number of Rows 1
    Row Spacing – Mating
    Number of Positions Loaded All
    Style Board to Cable/Wire
    Shrouding Shrouded – 4 Wall
    Mounting Type Surface Mount, Right Angle
    Termination Solder
    Fastening Type Detent Lock
    Contact Length – Mating
    Contact Length – Post
    Overall Contact Length
    Insulation Height 0.134″ (3.40mm)
    Contact Shape Rectangular
    Contact Finish – Mating Tin
    Contact Finish Thickness – Mating 39.4µin (1.00µm)
    Contact Finish – Post Tin
    Contact Material Phosphor Bronze
    Insulation Material Polyamide (PA46), Nylon 4/6
    Features Solder Retention
    Operating Temperature
    Ingress Protection
    Material Flammability Rating UL94 V-0
    Insulation Color Natural
    Current Rating (Amps)
    Voltage Rating
    Mated Stacking Heights
    Contact Finish Thickness – Post
    Applications Automotive, General Purpose, Industrial, Medical
    Base Product Number 53261
