52435-3071
INQUIRY ONLINE
|
Category
|
Connectors, Interconnects
FFC, FPC (Flat Flexible) Connectors
FFC, FPC (Flat Flexible) Connector Assemblies
|
|
|
Manufacturer
|
Molex
|
|
|
Series
|
Easy-On 52435
|
|
|
Packaging
|
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status
|
Active
|
|
|
Flat Flex Type
|
FFC, FPC
|
|
|
Mounting Type
|
Surface Mount, Right Angle
|
|
|
Connector/Contact Type
|
Contacts, Top
|
|
|
Number of Positions
|
30
|
|
|
Pitch
|
0.020″ (0.50mm)
|
|
|
Termination
|
Solder
|
|
|
FFC, FCB Thickness
|
0.30mm
|
|
|
Height Above Board
|
0.079″ (2.00mm)
|
|
|
Locking Feature
|
Slide Lock
|
|
|
Cable End Type
|
Straight, Tapered
|
|
|
Contact Material
|
Phosphor Bronze
|
|
|
Contact Finish
|
Gold
|
|
|
Housing Material
|
Polyamide (PA46), Nylon 4/6
|
|
|
Actuator Material
|
Polyphenylene Sulfide (PPS)
|
|
|
Features
|
Solder Retention, Zero Insertion Force (ZIF)
|
|
|
Voltage Rating
|
50V
|
|
|
Operating Temperature
|
-40°C ~ 85°C
|
|
|
Material Flammability Rating
|
UL94 V-0
|
|
|
Current Rating (Amps)
|
0.5A
|
|
|
Contact Finish Thickness
|
–
|
|
|
Housing Color
|
–
|
|
|
Actuator Color
|
–
|
|
|
Mating Cycles
|
20
|
|
|
Base Product Number
|
052435
|
