LMR14050SDDAR

IC REG BUCK ADJ 5A 8SOPWR


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    Category
    Integrated Circuits (ICs)
    PMIC
    Voltage Regulators – DC DC Switching Regulators
    Mfr
    Texas Instruments
    Series
    SIMPLE SWITCHER®
    Packaging
    Tape & Reel (TR)
    Cut Tape (CT)
    Digi-Reel®
    Part Status
    Active
    Function
    Step-Down
    Output Configuration
    Positive
    Topology
    Buck
    Output Type
    Adjustable
    Number of Outputs
    1
    Voltage – Input (Min)
    4V
    Voltage – Input (Max)
    40V
    Voltage – Output (Min/Fixed)
    0.8V
    Voltage – Output (Max)
    28V
    Current – Output
    5A
    Frequency – Switching
    200kHz ~ 2.5MHz
    Synchronous Rectifier
    No
    Operating Temperature
    -40°C ~ 125°C (TJ)
    Mounting Type
    Surface Mount
    Package / Case
    8-PowerSOIC (0.154″, 3.90mm Width)
    Supplier Device Package
    8-SO PowerPad
    Base Product Number
    LMR14050
