10132798-032100LF

Amphenol’s BergStak® 0.5mm is a comprehensive and
versatile board-to-board solution designed for reliable
and high-density applications. The unique design of
scoop-proof housing ensures terminals are not damaged
during mating.
TARGET MARKETS
BergStak® 0.5mm Mezzanine Connector
§ 0.5mm double row contact for high density connector
§ Scoop-proof housing ensures terminals are not damaged
during the mating
§ PCB locator pegs option helps to ease manual assembly


Download Details PDF

Notice:

In stock will ship in 2 days. Real-time inventory pls confirm with us.

INQUIRY ONLINE




    SPECIFICATION

    0.5mm double row contact § High density connector
    § Scoop-proof housings § Ensures terminals are not damaged during mating
    §Metal hold-down option § Higher retention force
    § Locating pegs option § Eases manual assembly
    § 3mm to 6mm stack heights in 0.5mm increments
    § 10 to 80 positions in 10 position increments
    § 7mm to 8.5mm stack heights in 0.5mm increments
    § 10 to 100 positions in 10 position increments
    § Wide range of sizes and stack heights supports different
    applications
    § Available in UL94 V0 § High flammability rating
    § USCAR-2 V1 shock and vibration qualified § Suitable for automotive applications
    § RoHS compliant and lead-free §Meets environmental, health, and safety requirements
