10114828-10104LF

Amphenol’s Basics Minitek® 1.25mm wire-to-board
connector system is designed for a wide variety of
applications in Industrial, Automotive, and Consumer
markets.
The comprehensive range consists of terminals, crimp
housings and PCB headers in straight and right angle,
surface mount and through-hole configurations. It
is available in 2 to 15 circuits in a single row. Minitek®
1.25mm wire-to-board solution conforms to the EU
Industry Safety Standard. PCB header material meets
halogen-free requirements and can be operated in the
temperature range from -40°C to +105°C.

§ Saves space with a 1.25mm pitch
§ Suitable for Industrial, Automotive, and Consumer markets
§ Crimp housing with friction feature
§ Conforms to EU Industry Safety Standard
§ Accommodates wire range up to 32AWG-28AWG
