VS-12CWQ06FNTR-M3
Part Number:
VS-12CWQ06FNTR-M3
Product Classification:
Toggle Switches
Manufacturer:
Aker Technology USA
Description:
DIODE ARRAY SCHOTTKY 60V 6A DPAK
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Discrete Semiconductor Products
Diodes
Rectifiers
Diode Arrays
|
|
|
Manufacturer |
Vishay General Semiconductor - Diodes Division
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Diode Configuration |
1 Pair Common Cathode
|
|
|
Technology |
Schottky
|
|
|
Voltage - DC Reverse (Vr) (Max) |
60 V
|
|
|
Current - Average Rectified (Io) (per Diode) |
6A
|
|
|
Voltage - Forward (Vf) (Max) @ If |
790 mV @ 12 A
|
|
|
Speed |
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Current - Reverse Leakage @ Vr |
3 mA @ 60 V
|
|
|
Operating Temperature - Junction |
150°C (Max)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
TO-252-3, DPAK (2 Leads + Tab), SC-63
|
|
|
Supplier Device Package |
TO-252AA (DPAK)
|
|
|
Base Product Number |
12CWQ06 |
