XAL6060-223MEC
零件编号：
XAL6060-223MEC
产品分类：
按钮开关 - 霍尔效应
制造商：
Altera
描述：
22 µH Shielded Molded Inductor 5 A 60.63mOhm Max Nonstandard
包装：
-
ROHS状态：
No
货币：
USD
| Mfr | Coilcraft |
| Series | XAL60XX |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Type | Molded |
| Material - Core | Metal Composite |
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 0.208333333 |
| Current - Saturation (Isat) | 5.6A |
| Shielding | Shielded |
| DC Resistance (DCR) | 60.63mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 9MHz |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.258" L x 0.250" W (6.56mm x 6.36mm) |
| Height - Seated (Max) | 0.240" (6.10mm) |
