- Meets or exceeds the requirements of the TIA/EIA-485A and TIA/EIA-422B standards
- Functional Safety-Capable
- Documentation available to aid functional safety system design
- 3-V to 5.5-V supply voltage
- Differential output exceeds 2.1 V for PROFIBUS compatibility with 5-V supply
- Bus I/O protection
- ±70-V DC bus fault
- ±16-kV HBM ESD
- ±12-kV IEC 61000-4-2 contact discharge
- ±12-kV IEC 61000-4-2 air-gap discharge
- ±4-kV IEC 61000-4-4 fast transient burst
- Half-duplex devices available in two speed grades
- THVD2410: 500 kbps
- THVD2450: 50 Mbps
- Extended ambient temperature range: -40°C to 125°C
- Extended operational common-mode range: ±25 V
- Enhanced receiver hysteresis for noise immunity
- Low power consumption
- Low shutdown supply current: < 1 µA
- Current during operation: < 5.6 mA
- Glitch-free power-up/down for hot plug-in capability
- Open, short, and idle bus failsafe
- Thermal shutdown
- 1/8 unit load (up to 256 bus nodes)
- Small VSON and VSSOP packages to save board space or SOIC for drop-in compatibility
