SWR204-NRTN-D04-ST-GA
零件编号：
SWR204-NRTN-D04-ST-GA
产品分类：
挖斗、钩子、探针、探针工具、调谐工具
制造商：
Amphenol PCD Shenzhen
描述：
CONN HEADER VERT 8POS 2MM
包装：
-
ROHS状态：
No
货币：
USD
PDF：
资料
|
Category |
Connectors, Interconnects
Rectangular Connectors
Headers, Male Pins
|
|
|
Mfr |
Sullins Connector Solutions |
|
|
Series |
SWR204 |
|
|
Packaging |
Bulk
|
|
|
Part Status |
Active
|
|
|
Connector Type |
Header |
|
|
Contact Type |
Male Pin
|
|
|
Pitch - Mating |
0.079" (2.00mm) |
|
|
Number of Positions |
8 |
|
|
Number of Rows |
2
|
|
|
Row Spacing - Mating |
0.079" (2.00mm) |
|
|
Number of Positions Loaded |
All
|
|
|
Style |
Board to Cable/Wire |
|
|
Shrouding |
Shrouded - 4 Wall
|
|
|
Mounting Type |
Through Hole |
|
|
Termination |
Solder
|
|
|
Fastening Type |
Detent Lock
|
|
|
Contact Length - Mating |
-
|
|
|
Contact Length - Post |
0.118" (3.00mm)
|
|
|
Overall Contact Length |
-
|
|
|
Insulation Height |
0.256" (6.50mm)
|
|
|
Contact Shape |
Square
|
|
|
Contact Finish - Mating |
Tin
|
|
|
Contact Finish Thickness - Mating |
-
|
|
|
Contact Finish - Post |
Tin
|
|
|
Contact Material |
Brass
|
|
|
Insulation Material |
Polyamide (PA66), Nylon 6/6
|
|
|
Features |
-
|
|
|
Operating Temperature |
-25°C ~ 85°C
|
|
|
Ingress Protection |
-
|
|
|
Material Flammability Rating |
UL94 V-0
|
|
|
Insulation Color |
Gray
|
|
|
Current Rating (Amps) |
3A per Contact
|
|
|
Voltage Rating |
50V
|
|
|
Mated Stacking Heights |
-
|
|
|
Contact Finish Thickness - Post |
-
|
|
|
Applications |
-
|
|
|
Base Product Number |
SWR204 |
