Category |
Integrated Circuits (ICs)
Logic
Translators, Level Shifters
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
74LVCC |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Translator Type |
Voltage Level
|
|
|
Channel Type |
Bidirectional
|
|
|
Number of Circuits |
1
|
|
|
Channels per Circuit |
8
|
|
|
Voltage - VCCA |
2.3 V ~ 3.6 V
|
|
|
Voltage - VCCB |
3 V ~ 5.5 V
|
|
|
Input Signal |
-
|
|
|
Output Signal |
-
|
|
|
Output Type |
Tri-State, Non-Inverted
|
|
|
Data Rate |
-
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
24-SOIC (0.295", 7.50mm Width)
|
|
|
Supplier Device Package |
24-SOIC
|
|
|
Base Product Number |
74LVCC3245 |
