Category |
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single FETs, MOSFETs
|
|
|
Mfr |
onsemi |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
FET Type |
P-Channel |
|
|
Technology |
MOSFET (Metal Oxide) |
|
|
Drain to Source Voltage (Vdss) |
20 V
|
|
|
Current - Continuous Drain (Id) @ 25°C |
1.3A (Ta) |
|
|
Drive Voltage (Max Rds On, Min Rds On) |
2.5V, 4.5V
|
|
|
Rds On (Max) @ Id, Vgs |
220mOhm @ 750mA, 4.5V
|
|
|
Vgs(th) (Max) @ Id |
1.25V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs |
5.5 nC @ 4 V
|
|
|
Vgs (Max) |
±12V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds |
225 pF @ 5 V
|
|
|
FET Feature |
-
|
|
|
Power Dissipation (Max) |
400mW (Ta)
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Grade |
-
|
|
|
Qualification |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Supplier Device Package |
SOT-23-3 (TO-236)
|
|
|
Package / Case |
TO-236-3, SC-59, SOT-23-3 |
|
|
Base Product Number |
NTR1P02 |
