Category |
Connectors, Interconnects
Coaxial Connectors (RF)
Coaxial Connector (RF) Assemblies
|
|
|
Mfr |
Samtec Inc. |
|
|
Series |
MCX |
|
|
Packaging |
Tray
|
|
|
Part Status |
Active
|
|
|
Connector Style |
MCX |
|
|
Connector Type |
Jack, Female Socket
|
|
|
Contact Termination |
Solder
|
|
|
Shield Termination |
Solder
|
|
|
Impedance |
75 Ohms
|
|
|
Mounting Type |
Through Hole
|
|
|
Mounting Feature |
-
|
|
|
Cable Group |
-
|
|
|
Fastening Type |
Snap-On
|
|
|
Frequency - Max |
6 GHz
|
|
|
Number of Ports |
1
|
|
|
Features |
-
|
|
|
Housing Color |
Gold
|
|
|
Ingress Protection |
-
|
|
|
Center Contact Material |
Beryllium Copper
|
|
|
Includes |
-
|
|
|
Body Material |
Brass
|
|
|
Body Finish |
Gold
|
|
|
Center Contact Plating |
Gold
|
|
|
Dielectric Material |
Polytetrafluoroethylene (PTFE)
|
|
|
Operating Temperature |
-65°C ~ 125°C
|
|
|
Voltage Rating |
170 V
|
|
|
Mating Cycles |
-
|
|
|
Insertion Loss |
-
|
|
|
Base Product Number |
MCX7-J |
