Category |
Integrated Circuits (ICs)
Power Management (PMIC)
LED Drivers
|
|
|
Manufacturer |
Analog Devices Inc.
|
|
|
Series |
-
|
|
|
Packaging |
Tube
|
|
|
Part Status |
Active
|
|
|
Type |
DC DC Controller
|
|
|
Topology |
Step-Down (Buck)
|
|
|
Internal Switch(s) |
No
|
|
|
Number of Outputs |
32
|
|
|
Voltage - Supply (Min) |
6V
|
|
|
Voltage - Supply (Max) |
55V
|
|
|
Voltage - Output |
-
|
|
|
Current - Output / Channel |
30mA
|
|
|
Frequency |
205Hz ~ 1.05MHz
|
|
|
Dimming |
PWM
|
|
|
Applications |
Backlight, Signage
|
|
|
Operating Temperature |
-40°C ~ 125°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
56-WFQFN Exposed Pad
|
|
|
Supplier Device Package |
56-QFN (5x9)
|
|
|
Base Product Number |
LT3746 |
|
