Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
|
|
|
Mfr |
Texas Instruments |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Obsolete
|
|
|
Output Configuration |
Positive |
|
|
Output Type |
Fixed |
|
|
Number of Regulators |
1
|
|
|
Voltage - Input (Max) |
26V
|
|
|
Voltage - Output (Min/Fixed) |
5V
|
|
|
Voltage - Output (Max) |
-
|
|
|
Voltage Dropout (Max) |
1V @ 500mA
|
|
|
Current - Output |
500mA |
|
|
Current - Quiescent (Iq) |
10 mA
|
|
|
Current - Supply (Max) |
20 mA
|
|
|
PSRR |
-
|
|
|
Control Features |
-
|
|
|
Protection Features |
Mirror-Image Insertion, Over Temperature, Short Circuit, Transient Voltage
|
|
|
Operating Temperature |
-40°C ~ 85°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
TO-261-4, TO-261AA
|
|
|
Supplier Device Package |
SOT-223-4
|
|
|
Base Product Number |
LM2937 |
