Category |
Integrated Circuits (ICs)
Power Management (PMIC)
DC DC Switching Controllers
|
|
|
Manufacturer |
Renesas Electronics Corporation
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
|
|
|
Part Status |
Active
|
|
|
Output Type |
Transistor Driver
|
|
|
Function |
Step-Up/Step-Down
|
|
|
Output Configuration |
Positive
|
|
|
Topology |
Buck-Boost
|
|
|
Number of Outputs |
1
|
|
|
Output Phases |
2
|
|
|
Voltage - Supply (Vcc/Vdd) |
4.5V ~ 80V
|
|
|
Frequency - Switching |
100kHz ~ 600kHz
|
|
|
Duty Cycle (Max) |
-
|
|
|
Synchronous Rectifier |
Yes
|
|
|
Clock Sync |
Yes
|
|
|
Serial Interfaces |
-
|
|
|
Control Features |
Current Limit, Enable, Off Time Control, On Time Control, Phase Control, Power Good, Power On Reset, Pulse Skipping, Ramp, Sequencing, Soft Start, Tracking
|
|
|
Operating Temperature |
-40°C ~ 125°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
32-WFQFN Exposed Pad
|
|
|
Supplier Device Package |
32-TQFN (5x5)
|
|
|
Base Product Number |
ISL81801 |
