HS100 47R J
零件编号：
HS100 47R J
产品分类：
以太网供电（PoE）
制造商：
Amazing
描述：
47 Ohms ±5% 100W Wirewound Chassis Mount Resistor
包装：
-
ROHS状态：
No
货币：
USD
Tolerance (Code): Standard ±5% (J) and ±10% (K). Also available ±1% (F), ±2% (G) and ±3% (H)
Tolerance for low Ω values: Typically ≥ R05 ±5% ≤ R047 ±10%
Temperature coefficients: Typical values < 1K 100ppm Std. > 1K 25ppm Std. For lower TCR’s please contact Arcol
Insulation resistance (Dry): 10,000 MΩ minimum
Power dissipation: At high ambient temperature dissipation derates linearly to zero at 200°C
Ohmic values:From R005 to 100K depending on wattage size
Low inductive (NHS):Specify by adding N before HS Series code, e.g. NHS50
NHS ohmic value:Divide standard HS maximum value by 4
NHS working volts:Divide standard HS maximum working voltage by 1.414
