Category |
Filters
Ferrite Beads and Chips
|
|
|
Manufacturer |
Shenzhen Sunlord Electronics Co., Ltd.
|
|
|
Series |
GZ-C |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Filter Type |
Signal Line
|
|
|
Number of Lines |
1
|
|
|
Impedance @ Frequency |
70 Ohms @ 100 MHz
|
|
|
Current Rating (Max) |
700mA
|
|
|
DC Resistance (DCR) (Max) |
100mOhm
|
|
|
Ratings |
-
|
|
|
Operating Temperature |
-55°C ~ 125°C
|
|
|
Package / Case |
0402 (1005 Metric)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Height (Max) |
0.026" (0.65mm)
|
|
|
Size / Dimension |
0.039" L x 0.020" W (1.00mm x 0.50mm)
|
