Category |
Connectors, Interconnects
FFC, FPC (Flat Flexible) Connectors
FFC, FPC (Flat Flexible) Connector Assemblies
|
|
|
Manufacturer |
Hirose Electric Co Ltd
|
|
|
Series |
FH34SRJ |
|
|
Packaging |
Tape & Reel (TR)
|
|
|
Part Status |
Obsolete
|
|
|
Flat Flex Type |
FFC, FPC
|
|
|
Mounting Type |
Surface Mount, Right Angle
|
|
|
Connector/Contact Type |
Contacts, Top and Bottom
|
|
|
Number of Positions |
20
|
|
|
Pitch |
0.020" (0.50mm)
|
|
|
Termination |
Solder
|
|
|
FFC, FCB Thickness |
0.30mm
|
|
|
Height Above Board |
0.039" (1.00mm)
|
|
|
Locking Feature |
Rotary Lock, Backlock
|
|
|
Cable End Type |
Tapered
|
|
|
Contact Material |
Phosphor Bronze
|
|
|
Contact Finish |
Gold
|
|
|
Housing Material |
Liquid Crystal Polymer (LCP), Halogen Free
|
|
|
Actuator Material |
Polyamide (PA), Nylon
|
|
|
Features |
Zero Insertion Force (ZIF)
|
|
|
Voltage Rating |
50V
|
|
|
Operating Temperature |
-55°C ~ 105°C
|
|
|
Material Flammability Rating |
UL94 V-0
|
|
|
Current Rating (Amps) |
0.5A
|
|
|
Contact Finish Thickness |
1.97µin (0.050µm)
|
|
|
Housing Color |
Gray
|
|
|
Actuator Color |
Black
|
|
|
Mating Cycles |
20
|
|
|
Base Product Number |
FH34SRJ |
