Category |
Integrated Circuits (ICs)
Power Management (PMIC)
AC DC Converters, Offline Switchers
|
|
|
Manufacturer |
onsemi
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Obsolete
|
|
|
Output Isolation |
Isolated
|
|
|
Internal Switch(s) |
No
|
|
|
Voltage - Breakdown |
-
|
|
|
Topology |
Flyback
|
|
|
Voltage - Start Up |
16 V
|
|
|
Voltage - Supply (Vcc/Vdd) |
7V ~ 25V
|
|
|
Duty Cycle |
75%
|
|
|
Frequency - Switching |
65kHz
|
|
|
Power (Watts) |
40 W
|
|
|
Fault Protection |
Current Limiting, Over Temperature, Over Voltage
|
|
|
Control Features |
-
|
|
|
Operating Temperature |
-40°C ~ 105°C (TA)
|
|
|
Package / Case |
SOT-23-6
|
|
|
Supplier Device Package |
SOT-23-6
|
|
|
Mounting Type |
Surface Mount
|
|
|
Base Product Number |
FAN6602 |
