Category |
Capacitors
Aluminum Electrolytic Capacitors
|
|
|
Mfr |
Panasonic Electronic Components |
|
|
Series |
M-A |
|
|
Packaging |
Cut Tape (CT)
Tape & Box (TB)
|
|
|
Part Status |
Active
|
|
|
Capacitance |
100 µF |
|
|
Tolerance |
±20%
|
|
|
Voltage - Rated |
100 V
|
|
|
ESR (Equivalent Series Resistance) |
-
|
|
|
Lifetime @ Temp. |
2000 Hrs @ 85°C
|
|
|
Operating Temperature |
-40°C ~ 85°C
|
|
|
Polarization |
Polar
|
|
|
Ratings |
-
|
|
|
Applications |
General Purpose |
|
|
Ripple Current @ Low Frequency |
350 mA @ 120 Hz
|
|
|
Ripple Current @ High Frequency |
595 mA @ 10 kHz
|
|
|
Lead Spacing |
0.197" (5.00mm)
|
|
|
Size / Dimension |
0.394" Dia (10.00mm)
|
|
|
Height - Seated (Max) |
0.669" (17.00mm)
|
|
|
Surface Mount Land Size |
-
|
|
|
Mounting Type |
Through Hole |
|
|
Package / Case |
Radial, Can
|
|
|
Base Product Number |
ECA-2AM |
