Category |
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
FET, MOSFET Arrays
|
|
|
Manufacturer |
Diodes Incorporated
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Technology |
MOSFET (Metal Oxide)
|
|
|
Configuration |
N and P-Channel
|
|
|
FET Feature |
Logic Level Gate
|
|
|
Drain to Source Voltage (Vdss) |
30V
|
|
|
Current - Continuous Drain (Id) @ 25°C |
3.8A, 2.5A
|
|
|
Rds On (Max) @ Id, Vgs |
55mOhm @ 3.4A, 10V
|
|
|
Vgs(th) (Max) @ Id |
1.5V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs |
12.3nC @ 10V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds |
422pF @ 15V
|
|
|
Power - Max |
850mW
|
|
|
Operating Temperature |
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
SOT-23-6 Thin, TSOT-23-6
|
|
|
Supplier Device Package |
TSOT-26
|
|
|
Base Product Number |
DMG6601 |
