Category |
Filters
Common Mode Chokes
|
|
|
Manufacturer |
Eaton - Electronics Division
|
|
|
Series |
CMS |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Filter Type |
Power Line
|
|
|
Number of Lines |
2
|
|
|
Inductance @ Frequency |
73.7 µH @ 100 kHz
|
|
|
Current Rating (Max) |
1.65A
|
|
|
DC Resistance (DCR) (Max) |
48mOhm (Typ)
|
|
|
Voltage Rating - DC |
-
|
|
|
Voltage Rating - AC |
-
|
|
|
Operating Temperature |
-40°C ~ 160°C
|
|
|
Ratings |
-
|
|
|
Approval Agency |
-
|
|
|
Features |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Size / Dimension |
0.370" L x 0.283" W (9.40mm x 7.20mm)
|
|
|
Height (Max) |
0.102" (2.60mm)
|
|
|
Package / Case |
Horizontal, 4 PC Pad
|
