BUK9M53-60EX
零件编号：
BUK9M53-60EX
产品分类：
固态继电器（SSR）
制造商：
Amphenol Fiber Systems International
描述：
MOSFET N-CH 60V 17A LFPAK33
包装：
-
ROHS状态：
No
货币：
USD
PDF：
资料
|
Category |
Discrete Semiconductor Products
Transistors
FETs, MOSFETs
Single FETs, MOSFETs
|
|
|
Mfr |
Nexperia USA Inc. |
|
|
Series |
TrenchMOS™ |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
FET Type |
N-Channel |
|
|
Technology |
MOSFET (Metal Oxide) |
|
|
Drain to Source Voltage (Vdss) |
60 V
|
|
|
Current - Continuous Drain (Id) @ 25°C |
17A (Tc) |
|
|
Drive Voltage (Max Rds On, Min Rds On) |
5V
|
|
|
Rds On (Max) @ Id, Vgs |
46mOhm @ 5A, 10V
|
|
|
Vgs(th) (Max) @ Id |
2.1V @ 1mA
|
|
|
Gate Charge (Qg) (Max) @ Vgs |
6 nC @ 5 V
|
|
|
Vgs (Max) |
±10V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds |
683 pF @ 25 V
|
|
|
FET Feature |
-
|
|
|
Power Dissipation (Max) |
36W (Tc)
|
|
|
Operating Temperature |
-55°C ~ 175°C (TJ)
|
|
|
Grade |
Automotive
|
|
|
Qualification |
AEC-Q101
|
|
|
Mounting Type |
Surface Mount
|
|
|
Supplier Device Package |
LFPAK33
|
|
|
Package / Case |
SOT-1210, 8-LFPAK33 (5-Lead) |
|
|
Base Product Number |
BUK9M53 |
