Input Voltage Range: 2.7V to 5.5V
50mΩ On-Resistance
Built-in Soft-Start with 0.6ms Typical Rise Time
Fault Report (FLG) with Blanking Time (6ms Typ.)
ESD Protection: 2kV HBM, 200V MM
Active Low (B) or Active High (A) Enable
Protection
Over Current with Auto Recovery
Short Circuit with Auto Recovery
Over Temperature with Auto Recovery
Output Reverse Current/Voltage Protection
Thermally Efficient Low Profile Package
UL Recognized, File Number E322375
IEC60950-1 CB Scheme Certified
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
For automotive applications requiring specific change
control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP
capable, and manufactured in IATF 16949 certified facilities),
please contact us or your local Diodes representative.
