88E1512-A0-NNP2I000

Four RGMII timing modes including integrated delays

• This eliminates the need for adding additional trace delays on the
PCB
Supports EEE (IEEE 802.3az)
- Implements EEE with legacy or non-EEE MAC
• Extended energy savings through incorporation of the IEEE
802.3az standard
- Additional support added to allow EEE enablement on non-EEE
MACs
Synchronous Ethernet

• Accurate and low-cost clock recovery for Time-aware applications
IEEE 1588v2 support

• Enables highly accurate Precision Timing Protocol applications
including wireless backhaul
Wake on LAN (WoL)

• Provides programmable lower power (S5) event/pattern and link
change detection
Integrated Switching Voltage Regulator

• Allows devices to run off single 3.3V supply
Advanced Virtual Cable Tester® (VCT™)

• Detects and reports potential cabling issues to within one meter of
the distance to the fault
48-pin QFN 7 mm x 7 mm Green package

• Environmentally friendly, small form factor for minimal real estate
requirements
