Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Gate Drivers
|
|
|
Manufacturer |
Infineon Technologies
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
DigiKey Programmable |
Not Verified
|
|
|
Driven Configuration |
Half-Bridge
|
|
|
Channel Type |
Synchronous
|
|
|
Number of Drivers |
2
|
|
|
Gate Type |
IGBT, MOSFET (N-Channel)
|
|
|
Voltage - Supply |
10V ~ 20V
|
|
|
Logic Voltage - VIL, VIH |
1.1V, 1.7V
|
|
|
Current - Peak Output (Source, Sink) |
2.5A, 2.5A
|
|
|
Input Type |
Non-Inverting
|
|
|
High Side Voltage - Max (Bootstrap) |
675 V
|
|
|
Rise / Fall Time (Typ) |
15ns, 15ns
|
|
|
Operating Temperature |
-40°C ~ 125°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-SOIC (0.154", 3.90mm Width)
|
|
|
Supplier Device Package |
PG-DSO-8-69
|
|
|
Base Product Number |
2ED2184 |
