Category |
Circuit Protection
PTC Resettable Fuses
|
|
|
Manufacturer |
Littelfuse Inc.
|
|
|
Series |
POLY-FUSE®, 2920L |
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Type |
Polymeric
|
|
|
Voltage - Max |
24V
|
|
|
Current - Hold (Ih) (Max) |
2 A
|
|
|
Current - Trip (It) |
4 A
|
|
|
Current - Max |
40 A
|
|
|
Time to Trip |
5 s
|
|
|
Resistance - Initial (Ri) (Min) |
50 mOhms
|
|
|
Resistance - Post Trip (R1) (Max) |
125 mOhms
|
|
|
Operating Temperature |
-40°C ~ 85°C
|
|
|
Ratings |
-
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
2920 (7351 Metric), Concave
|
|
|
Size / Dimension |
0.289" L x 0.202" W (7.35mm x 5.12mm)
|
|
|
Height - Seated (Max) |
-
|
|
|
Thickness (Max) |
0.049" (1.25mm)
|
|
|
Lead Spacing |
-
|
|
|
Approval Agency |
cURus, TUV
|
