TXS0104EPWR

• No direction-control signal needed
• Maximum data rates:
– 24Mbps (push pull)
– 2Mbps (open drain)
• Available in the Texas Instruments NanoFree™
package
• 1.65 V to 3.6 V on A port and 2.3 V to 5.5 V on B
port (VCCA ≤ VCCB)
• No power-supply sequencing required – VCCA or
VCCB can be ramped first
• Latch-up performance exceeds 100 mA per JESD
78, class II
• ESD protection exceeds JESD 22:
– A port:
• 2000-V Human-Body Model (A114-B)
• 200-V Machine Model (A115-A)
• 1000-V Charged-Device Model (C101)
– B port:
• 15-kV Human-Body Model (A114-B)
• 200-V Machine Model (A115-A)
• 1000-V Charged-Device Model (C101)
• IEC 61000-4-2 ESD (B port):
– ±8-kV contact discharge
– ±10-kV air-gap discharge
