TS5A3159DCKR
Part Number:
TS5A3159DCKR
Product Classification:
Bipolar RF Transistors
Manufacturer:
3PEAK
Description:
IC SWITCH SPDT X 1 1.1OHM SC70-6
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Switch Circuit |
SPDT
|
|
|
Multiplexer/Demultiplexer Circuit |
2:1
|
|
|
Number of Circuits |
1
|
|
|
On-State Resistance (Max) |
1.1Ohm
|
|
|
Channel-to-Channel Matching (ΔRon) |
100mOhm
|
|
|
Voltage - Supply, Single (V+) |
1.65V ~ 5.5V
|
|
|
Voltage - Supply, Dual (V±) |
-
|
|
|
Switch Time (Ton, Toff) (Max) |
35ns, 20ns
|
|
|
-3db Bandwidth |
100MHz
|
|
|
Charge Injection |
36pC
|
|
|
Channel Capacitance (CS(off), CD(off)) |
23pF
|
|
|
Current - Leakage (IS(off)) (Max) |
2nA
|
|
|
Crosstalk |
-65dB @ 1MHz
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
6-TSSOP, SC-88, SOT-363
|
|
|
Supplier Device Package |
SC-70-6
|
|
|
Base Product Number |
TS5A3159 |
