TPS54202DDCR

• 4.5-V to 28-V wide input voltage range
• Integrated 148-mΩ and 78-mΩ MOSFETs for 2-A,
continuous output current
• Low 2-μA shutdown, 45-μA quiescent current
• Internal 5-mS soft start
• Fixed 500-kHz switching frequency
• Frequency spread spectrum to reduce EMI
• Advanced Eco-mode™ pulse skip
• Peak current mode control
• Internal loop compensation
• Overcurrent protection for both MOSFETs with
hiccup mode protection
• Overvoltage protection
• Thermal shutdown
• SOT-23 (6) package
