TPD4E05U06DQAR
Part Number:
TPD4E05U06DQAR
Product Classification:
Configurable Switch Lens
Manufacturer:
3PEAK
Description:
14V Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 10-USON (2.5x1)
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
• IEC 61000-4-2 level 4 ESD protection
– ±12-kV contact discharge
– ±15-kV air gap discharge
• IEC 61000-4-4 EFT protection
– 80 A (5/50 ns)
• IEC 61000-4-5 surge protection
– 2.5 A (8/20 µs)
• IO capacitance 0.42 pF to 0.5 pF (typical)
• DC breakdown voltage 6.5 V (minimum)
• Ultra low leakage current 10 nA (maximum)
• Low ESD clamping voltage
• Industrial temperature range: –40°C to +125°C
• Easy straight-through routing packages
• Industry standard SOD-523 package
(1.60 mm × 0.80 mm × 0.65 mm)
