TLE75008ESD
Part Number:
TLE75008ESD
Product Classification:
Power Transformers
Manufacturer:
AC Tasarim
Description:
Power Switch Lo Side 8-OUT 0.33A 1Ohm Automotive AEC-Q100 24-Pin TSDSO EP T/R
Packaging:
-
ROHS Status:
No
Currency:
USD
| Mfr | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Switch Type | Relay, Solenoid Driver |
| Number of Outputs | 8 |
| Ratio - Input:Output | 1:08 |
| Output Configuration | Low Side |
| Output Type | N-Channel |
| Interface | SPI |
| Voltage - Load | 3V ~ 28V |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Current - Output (Max) | 330mA |
| Rds On (Typ) | 1Ohm |
| Input Type | - |
| Features | Slew Rate Controlled |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TSDSO-24-51 |
| Package / Case | 24-TSSOP (0.154", 3.90mm Width) Exposed Pad |
| Base Product Number | TLE75008 |
