SS54F
Part Number:
SS54F
Product Classification:
Toggle Switches
Manufacturer:
Bestact Solutions Inc.
Description:
DIODE SCHOTTKY 40V 5A SMAF
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Discrete Semiconductor Products
Diodes
Rectifiers
Single Diodes
|
|
|
Mfr |
MDD |
|
|
Series |
SS5 |
|
|
Packaging |
Tape & Reel (TR)
|
|
|
Part Status |
Active
|
|
|
Technology |
Schottky |
|
|
Voltage - DC Reverse (Vr) (Max) |
40 V
|
|
|
Current - Average Rectified (Io) |
5A
|
|
|
Voltage - Forward (Vf) (Max) @ If |
550 mV @ 5 A
|
|
|
Speed |
Fast Recovery =< 500ns, > 200mA (Io)
|
|
|
Current - Reverse Leakage @ Vr |
500 µA @ 40 V
|
|
|
Capacitance @ Vr, F |
200pF @ 4V, 1MHz
|
|
|
Mounting Type |
Surface Mount |
|
|
Package / Case |
DO-221AC, SMA Flat Leads |
|
|
Supplier Device Package |
SMAF
|
|
|
Operating Temperature - Junction |
-55°C ~ 125°C
|
