RT9611AGQW
Part Number:
RT9611AGQW
Product Classification:
Keylock Switches
Manufacturer:
Amgis
Description:
IC GATE DRVR HI/LOW SIDE 8WDFN
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Gate Drivers
|
|
|
Manufacturer |
Richtek USA Inc.
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
DigiKey Programmable |
Not Verified
|
|
|
Driven Configuration |
High-Side or Low-Side
|
|
|
Channel Type |
Synchronous
|
|
|
Number of Drivers |
2
|
|
|
Gate Type |
N-Channel MOSFET
|
|
|
Voltage - Supply |
4.5V ~ 13.5V
|
|
|
Logic Voltage - VIL, VIH |
-
|
|
|
Current - Peak Output (Source, Sink) |
-
|
|
|
Input Type |
Non-Inverting
|
|
|
High Side Voltage - Max (Bootstrap) |
15 V
|
|
|
Rise / Fall Time (Typ) |
12ns, 12ns
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
8-WFDFN Exposed Pad
|
|
|
Supplier Device Package |
8-WDFN-EL (3x3)
|
|
|
Base Product Number |
RT9611 |
