Category |
Isolators
Optocouplers, Optoisolators
Transistor, Photovoltaic Output Optoisolators
|
|
|
Manufacturer |
Renesas Electronics Corporation
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Not For New Designs
|
|
|
Number of Channels |
4
|
|
|
Voltage - Isolation |
2500Vrms
|
|
|
Current Transfer Ratio (Min) |
80% @ 5mA
|
|
|
Current Transfer Ratio (Max) |
600% @ 5mA
|
|
|
Turn On / Turn Off Time (Typ) |
6µs, 5µs
|
|
|
Rise / Fall Time (Typ) |
3µs, 5µs
|
|
|
Input Type |
DC
|
|
|
Output Type |
Transistor
|
|
|
Voltage - Output (Max) |
80V
|
|
|
Current - Output / Channel |
50mA
|
|
|
Voltage - Forward (Vf) (Typ) |
1.1V
|
|
|
Current - DC Forward (If) (Max) |
50 mA
|
|
|
Vce Saturation (Max) |
300mV
|
|
|
Operating Temperature |
-55°C ~ 100°C
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
16-SOIC (0.173", 4.40mm Width)
|
|
|
Supplier Device Package |
16-SSOP
|
|
|
Base Product Number |
PS2801 |
