P24C04C-SSH-MIR

 Single Supply Voltage and High Speed
 Minimum operating voltage down to 1.7V
 1 MHz clock from 2.5V to 5.5V
 400kHz clock from 1.7V to 2.5V
 Low power CMOS technology
 Read current 400uA, maximum
 Write current 1.6mA, maximum
 Schmitt Trigger, Filtered Inputs for Noise Suppression
 Sequential & Random Read Features
 Page Write Modes, Partial Page Writes Allowed
 Write protect of the whole memory array
 Additional Write Lockable Page and 128-bit Serial Number
 Self-timed Write Cycle (5ms maximum)
 High Reliability
 Endurance: > 1 Million Write Cycles
 Data Retention: > 100 Years
 HBM: 6KV
 Latch up Capability: +/- 200mA (25°C & 125°C)
 Package: PDIP-8, SOP-8, TSSOP-8, DFN-8/UDFN-8, SOT23-5,TSOT23-5, and 6-ball WLCSP
