MP3425DL-LF-Z
Part Number:
MP3425DL-LF-Z
Product Classification:
Keylock Switches
Manufacturer:
Allegro MicroSystems
Description:
IC REG BOOST ADJ 3A 14QFN
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - DC DC Switching Regulators
|
|
|
Mfr |
Monolithic Power Systems Inc. |
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Function |
Step-Up
|
|
|
Output Configuration |
Positive
|
|
|
Topology |
Boost |
|
|
Output Type |
Adjustable |
|
|
Number of Outputs |
1
|
|
|
Voltage - Input (Min) |
3.1V
|
|
|
Voltage - Input (Max) |
22V
|
|
|
Voltage - Output (Min/Fixed) |
3.1V |
|
|
Voltage - Output (Max) |
55V (Switch)
|
|
|
Current - Output |
3A (Switch) |
|
|
Frequency - Switching |
300kHz ~ 2MHz
|
|
|
Synchronous Rectifier |
No
|
|
|
Operating Temperature |
-40°C ~ 85°C (TA)
|
|
|
Mounting Type |
Surface Mount
|
|
|
Package / Case |
14-VFDFN Exposed Pad |
|
|
Supplier Device Package |
14-QFN (3x4)
|
|
|
Base Product Number |
MP3425 |
