LM5021MMX-1 NOPB
Part Number:
LM5021MMX-1 NOPB
Product Classification:
Keylock Switches
Manufacturer:
3PEAK
Description:
IC OFFLINE SWITCH FLYBACK 8VSSOP
Packaging:
-
ROHS Status:
No
Currency:
USD
PDF:
Documents
|
Category |
Integrated Circuits (ICs)
Power Management (PMIC)
AC DC Converters, Offline Switchers
|
|
|
Manufacturer |
Texas Instruments
|
|
|
Series |
-
|
|
|
Packaging |
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
|
|
|
Part Status |
Active
|
|
|
Output Isolation |
Isolated
|
|
|
Internal Switch(s) |
No
|
|
|
Voltage - Breakdown |
-
|
|
|
Topology |
Flyback
|
|
|
Voltage - Start Up |
20 V
|
|
|
Voltage - Supply (Vcc/Vdd) |
8V ~ 30V
|
|
|
Duty Cycle |
80%
|
|
|
Frequency - Switching |
150kHz ~ 1MHz
|
|
|
Fault Protection |
Current Limiting, Over Load
|
|
|
Control Features |
Frequency Control, Soft Start, Sync
|
|
|
Operating Temperature |
-40°C ~ 125°C (TJ)
|
|
|
Package / Case |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
|
|
|
Supplier Device Package |
8-VSSOP
|
|
|
Mounting Type |
Surface Mount
|
|
|
Base Product Number |
LM5021 |
